This project implements a raycaster on nvidia GPUs, visualizing wind patterns through the use of silhouette shading
## Table of Contents * [About the Project](#about) * [Dependencies](#dependencies) * [Installation](#installation) * [Running](#running) * [Screenshots](#screenshots) * [Modules](#modules) ## About This project was developed as part of the course Geo-Visualization at the University of Groningen. It contains a CUDA-based raycaster which visualizes wind patterns using a silhouette shading. The program also includes various configuration options, which can be set as the program runs (see [Screenshots](#screenshots)). The program expects to use the MERRA2 dataset, which can be found [here](https://disc.gsfc.nasa.gov/datasets/M2I6NPANA_5.12.4/summary?keywords=M2I6NPANA_5.12.4). ## Dependencies The project depends on a few libraries. Below is a list of these along with versions that _will_ work. Newer/older versions of the libraries may also compile and run properly, but this has not been tested. * OpenGL[^1] Tested using the Mesa (1:24.3.3-2) driver. * glfw3 (3.4-2) * Cuda (12.6.3-1) * Netcdf (4.9.2-6) * Netcdf-cxx (4.3.1-4) * Dear ImGUI (submodule within repository) ## Installation Once all libraries are installed compiling the program is quite straightforward. First, initialize the Dear ImGUI submodule: ```bash git submodule update --init ``` Then compile using CMake: ```bash mkdir build cd build cmake .. make ./cuda-raytracer ``` Make sure the program is executed on the nvidia GPU, or it will crash on startup. For example, on Arch the command `prime-run ./cuda-raytracer` would make sure the program utilizes the GPU. ## Running ### A note on data loading In order to run properly, the program expects to find a number of `.nc4` files in a directory relative to the executable. Specifically, the data should consist of a number of `.nc4` files from the MERRA2 dataset, located in the `./data/trimmed/` folder. For best results - that is, to ensure no crashes during runtime - this folder should contain a full year of data. The program loads a specific data file based on index, meaning the files should be named in alphabetical order. For example, using the date of the file in question is a good way of ensuring this: * MERRA2_400.inst6_3d_ana_Np.20120101.nc4 * MERRA2_400.inst6_3d_ana_Np.20120102.nc4 * MERRA2_400.inst6_3d_ana_Np.20120103.nc4 * MERRA2_400.inst6_3d_ana_Np.20120104.nc4 ### Actual execution Once the data is in place, the program may be executed as normal - again make sure to run this on an NVidia GPU. ## Screenshots Temperature of hurricane Sandy visualized using the raycaster over time:  Note: We figured this out only after the presentation on 24 Jan 2025.
